For operations seeking quail cages for sale,designed for maximum productivity, commercial quail cages feature multi-tiered galvanized steel structures (275g/m² coating) with optimized 250mm inter-tier clearance, enabling efficient waste management and airflow. Integrated laser-guided feeding systems achieve ±1g feed accuracy per bird, while centralized egg belts reduce breakage below 0.5%. These systems support high-density farming compliant with EU animal welfare standards at 80-100 birds/m².
Top Breeds
Brown Quail:
Preferred by 80% farmers for disease resistance & adaptability.
White Quail:
Chinese White Quail variant, leaner body composition
Key Metrics
| Parameter | Value |
|---|---|
| Adult Weight | 130g/bird |
| Egg Weight | 12g/egg (40 eggs/lb) |
| Daily Feed Intake | 22g/bird |
Critical Parameters
| Growth Stage | Temperature | Humidity | Light Hours |
|---|---|---|---|
| Chicks (0-3 wks) | 35-37°C | 60-70% | 16-20 hrs |
| Adults | 20-26°C | 50-60% | 8-10 hrs |
Ventilation Protocol
Optimal Layout
Engineering Specs
| Component | Specification |
|---|---|
| Cage Frame | Galvanized steel (2mm wire) |
| Feeding Side Height | 125mm |
| Egg Collection Side | 175mm (external egg belt) |
| Water System | Nipple drinkers (egg side) |
Barn Dimensions
| Layout | Width | Height |
|---|---|---|
| 4-column | 9-10.5m | ≥3.3m |
| 6-column | 12.5-13.5m | ≥3.3m |
| 8-column | ≈17m | ≥3.3m |
Automation Systems
Sample Barn: 90m (L) × 13.5m (W) × 3.5m (H)
Cage Units Calculation:
90m - 1.5m (manure channel) - 1.2m (ditch) - 1.4m (manure machine clearance) - 1.3m (egg collector space) - 1.5m (egg collection line) = 83.1m Usable length: 83.1m ÷ 1.2m/unit = 69 units Total birds: 69 units × 6 columns × 90 birds/layer × 6 layers = 223,560 quail
Climate Equipment:
Why This System Works
A Chinese farm using this model achieved:
✅ 95% egg integrity rate
✅ 18% lower feed waste
✅ 5% higher survival rate vs open systems
Ready to optimize your quail operation? Request our cage design templates or ventilation CFD analysis! 🐤
